HOMAN Oil tankers
HOMAN 4×2 Fuel bowser
Fuel-delivery configurations with 6 m³ or 10 m³ tanks for your distribution and refuelling operation.
Choose the power, then the features that change.
Your selected vehicle and configuration will be included.
Specifications updated for JM-HOMAN-4X2-FUEL-BOWSER-W20260526-L03
Your complete specification sheet
115 hp · 1061（4.2T）/CentralsingleReduction，Ratio：5.375
Engine and transmission
| Engine model | YC4FA115-33 |
|---|---|
| Engine displacement | 2.982 L |
| Engine output as listed | 115HP |
| Emission standard as listed | Euro II |
| Gearbox | WLY10H46 / 5 forword&1 reverse / Manuall / With PTO |
Body and dimensions
| Body tank volume as listed | 6 m³ |
|---|---|
| Body equipment as listed | Tank material Carbon steel Q235 With copper gear oil pump With a set of refueling system（1 inch refueling gun , 15m oil tube, mechanical flowmeter） It has the function of pressure drainage and self-flow drainage Exhaust emission position: Standard position, side of vehicle (not modified to front exhaust) |
Axles and chassis
| Wheelbase as listed | 3400mm |
|---|---|
| Steering | Left hand drive / Hydraulically assisted |
| Front axle | 1061（2.4T）/ Forging I-beam front axle |
| Rear axle and ratio | 1061（4.2T）/ Central single Reduction，Ratio：5.375 |
| Tyres | 7.00R16×7 / With one spare tire / Total 7 pieces |
| Chassis fuel tank | 120L （Iron） |
| Manufacturer load class as listed | 5T |
Cabin and equipment
| Cabin | 1880 cabin / Driver seat / 2 Passenger seats / A/C |
|---|---|
| Cabin equipment | Central locking / Electric doors and Windows |
Configuration reference: JM-HOMAN-4X2-FUEL-BOWSER-W20260526-L03Manufacturer model: ZZ1048D3414C1
Your quotation confirms the final specification, availability and delivery terms.
Choose the complete tank and chassis combination below. Confirm fuel compatibility, dispensing equipment and site requirements in your quotation.
