HOMAN Refrigerated vans
HOMAN 4×2 Refrigerated truck
An insulated delivery body with a Carrier C500 refrigeration unit for temperature-controlled transport requirements.
Your selected vehicle and configuration will be included.
Specifications updated for JM-HOMAN-4X2-REFRIGERATED-VAN-W20260526-L07
Your complete specification sheet
160 hp · 2,050 mm · 1118（8.0T）/CentralsingleReduction/Ratio：5.833
Engine and transmission
| Engine model | YC4E160-33 |
|---|---|
| Engine displacement | 4.257 L |
| Engine output as listed | 160HP / 160PS |
| Emission standard as listed | Euro II |
| Gearbox | 8JS85TE（FAST） / 8 forword&2 reverse / Manual / With PTO |
Body and dimensions
| Body dimensions as listed | 4785*2250*2050mm |
|---|---|
| Body equipment as listed | Thickness：Top and bottom: 105 mm Front and rear: 82.5 mm Left and right side panels: 75 mm Refrigeration Unit: Carrier C500 Split System Unit (Without Backup Power), the body adopts Geer wet process panel manufacturing, with the floor equipped with heavy-duty T-type aluminum guide rails B2-grade polyurethane insulation material |
Axles and chassis
| Wheelbase as listed | 3800mm |
|---|---|
| Steering | Left hand drive / Hydraulically assisted |
| Front axle | 1090（3.2T） / Forging l-beam front axle |
| Rear axle and ratio | 1118（8.0T） / Central single Reduction / Ratio：5.833 |
| Tyres | 9.00R20 / With one spare tire / Total 7 pieces |
| Chassis fuel tank | 200L (Aluminum) |
Cabin and equipment
| Cabin | 2080 cabin / 2 Passenger seats / 1 small sleeper / A/C |
|---|---|
| Cabin equipment | Central locking / Electric doors and Windows / Air deflector |
Configuration reference: JM-HOMAN-4X2-REFRIGERATED-VAN-W20260526-L07Manufacturer model: ZZ1168G3815C1
Your quotation confirms the final specification, availability and delivery terms.
Tell us your goods, target temperature, journey length and door-opening frequency. The listed Carrier C500 split system has no backup power; temperature performance must be confirmed for your duty cycle.
